Configuring VLAN Translation
– 585 –
Figure 8: Configuring VLAN Translation
â—† The maximum number of VLAN translation entries is 8 per port, and up to 96 for
the system. However, note that configuring a large number of entries may
degrade the performance of other processes that also use the TCAM, such as IP
Source Guard filter rules, Quality of Service (QoS) processes, QinQ, MAC-based
VLANs, VLAN translation, or traps.
â—† If VLAN translation is set on an interface with this command, and the same
interface is also configured as a QinQ access port with the switchport
dot1q-tunnel mode command, VLAN tag assignments will be determined by
the QinQ process, not by VLAN translation.
Example
This example configures VLAN translation for Port 1 as described in the Command
Usage section above.
Console(config)#vlan database
Console(config-vlan)#vlan 10 media ethernet state active
Console(config-vlan)#vlan 100 media ethernet state active
Console(config-vlan)#exit
Console(config)#interface ethernet 1/1,2
Console(config-if)#switchport allowed vlan add 10 tagged
Console(config-if)#switchport allowed vlan add 100 tagged
Console(config-if)#interface ethernet 1/1
Console(config-if)#switchport vlan-translation 10 100
Console(config-if)#end
Console#show vlan-translation
Interface Old VID New VID
--------- ------- -------
Eth 1/ 1 10 100
Console#
show vlan-translation This command displays the configuration settings for VLAN translation.
Syntax
show vlan-translation [interface interface]
interface
ethernet unit/port
unit - Stack unit. (Range: 1)
port - Port number. (Range: 1-28/52)
