Edge-Core ECS4120-52T Reference Guide

Chapter 8 | Authentication Commands
802.1X Port Authentication
– 259 –
dot1x max-reauth-req This command sets the maximum number of times that the switch sends an EAP-
request/identity frame to the client before restarting the authentication process.
Use the no form to restore the default.
Syntax
dot1x max-reauth-req count
no dot1x max-reauth-req
count – The maximum number of requests (Range: 1-10)
Default
2
Command Mode
Interface Configuration
Example
Console(config)#interface eth 1/2
Console(config-if)#dot1x max-reauth-req 2
Console(config-if)#
dot1x max-req This command sets the maximum number of times the switch port will retransmit
an EAP request/identity packet to the client before it times out the authentication
session. Use the no form to restore the default.
Syntax
dot1x max-req count
no dot1x max-req
count – The maximum number of requests (Range: 1-10)
Default
2
Command Mode
Interface Configuration
Example
Console(config)#interface eth 1/2
Console(config-if)#dot1x max-req 2
Console(config-if)#

Edge-Core ECS4120-52T Specifications

General

Device Type	Managed Switch
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
MAC Address Table Size	16K
DRAM	512 MB
Ports	48 x 10/100/1000BASE-T
Jumbo Frame Support	Up to 9KB
CPU	800MHz
Power Supply	AC 100-240V, 50-60Hz
Operating Temperature	0°C to 50°C
Storage Temperature	70 °C
Dimensions (W x D x H)	440 x 44 mm
Layer	Layer 2 / Layer 3 Lite
Humidity	10% to 90% (non-condensing)
