Chapter 30

| IP Interface Commands

ND Snooping

– 896 –

show ipv6 nd

snooping prefix

This command shows all entries in the address prefix table.

Syntax

show ipv6 nd snooping prefix [interface vlan vlan_id]

vlan-id - VLAN ID. (Range: 1-4094)

Command Mode

Privileged Exec

Example

Console#show ipv6 nd snooping prefix

Prefix entry timeout: 100 (second)

Prefix Len Valid-Time Expire VLAN Interface

-------------------------------------- --- ---------- ---------- ---- ---------

2001:b000:: 64 2592000 100 1 Eth 1/1

2001:: 64 600 34 2 Eth 1/2

Console#
