Edge-Core ECS4120-52T Reference Guide

Chapter 5 | SNMP Commands
SNMPv3 Commands
– 194 –
show snmp user This command shows information on SNMP users.
Command Mode
Privileged Exec
Example
Console#show snmp user
Engine ID : 8000018403fc0a81b7c7e00000
User Name : steve
Group Name : r&d
Security Model : v3
Security Level : Authentication and privacy
Authentication Protocol : MD5
Privacy Protocol : DES56
Storage Type : Nonvolatile
Row Status : Active
SNMP remote user
Engine ID : 9876543210
User Name : mark
Group Name : r&d
Security Model : v3
Security Level : Authentication and privacy
Authentication Protocol : MD5
Privacy Protocol : DES56
Storage Type : Nonvolatile
Row Status : Active
Console#
show snmp view This command shows information on the SNMP views.
Command Mode
Privileged Exec
Example
Console#show snmp view
View Name: mib-2
Table 32: show snmp user - display description
Field Description
Engine ID String identifying the engine ID.
User Name Name of user connecting to the SNMP agent.
Group Name The authentication protocol used with SNMPv3.
Security Model The privacy protocol used with SNMPv3.
Security Level The storage type for this entry.
Authentication Protocol The row status of this entry.
Privacy Protocol A user associated with an SNMP engine on a remote device.

Edge-Core ECS4120-52T Specifications

General

Device Type	Managed Switch
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
MAC Address Table Size	16K
DRAM	512 MB
Ports	48 x 10/100/1000BASE-T
Jumbo Frame Support	Up to 9KB
CPU	800MHz
Power Supply	AC 100-240V, 50-60Hz
Operating Temperature	0°C to 50°C
Storage Temperature	70 °C
Dimensions (W x D x H)	440 x 44 mm
Layer	Layer 2 / Layer 3 Lite
Humidity	10% to 90% (non-condensing)
