Edge-Core ECS4120-52T Reference Guide

Chapter 8 | Authentication Commands
PPPoE Intermediate Agent
– 274 –
Command Usage
If the delimiter is enabled and it occurs in the remote ID string, the string will be
truncated at that point.
Example
This command enables the delimiter for port 5.
Console(config)#interface ethernet 1/5
Console(config-if)#pppoe intermediate-agent port-format-type remote-id
Console(config-if)#
pppoe intermediate-
agent trust
This command sets an interface to trusted mode to indicate that it is connected to a
PPPoE server. Use the no form to set an interface to untrusted mode.
Syntax
[no] pppoe intermediate-agent trust
Default Setting
Untrusted
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
◆ Set any interfaces connecting the switch to a PPPoE Server as trusted.
Interfaces that connect the switch to users (PPPoE clients) should be set as
untrusted.
◆ At least one trusted interface must be configured on the switch for the PPPoE
IA to function.
Example
Console(config)#interface ethernet 1/5
Console(config-if)#pppoe intermediate-agent trust
Console(config-if)#
pppoe intermediate-
agent vendor-tag strip
This command enables the stripping of vendor tags from PPPoE Discovery packets
sent from a PPPoE server. Use the no form to disable this feature.
Syntax
[no] pppoe intermediate-agent vendor-tag strip
Default Setting
Disabled

Edge-Core ECS4120-52T Specifications

General

Device Type	Managed Switch
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
MAC Address Table Size	16K
DRAM	512 MB
Ports	48 x 10/100/1000BASE-T
Jumbo Frame Support	Up to 9KB
CPU	800MHz
Power Supply	AC 100-240V, 50-60Hz
Operating Temperature	0°C to 50°C
Storage Temperature	70 °C
Dimensions (W x D x H)	440 x 44 mm
Layer	Layer 2 / Layer 3 Lite
Humidity	10% to 90% (non-condensing)
