Edgetech 6205S - Figure 2-1: 6205 S Sonar Head Components

2-5
Figure 2-1: 6205s Sonar Head Components
NOTE: The terms used in Figure 2-1 are referenced throughout this
manual.
HOUSING
M
OUNTING
P
LATE
SONAR PROCESSOR
SOUND VELOCITY SENSOR (SVS)
SONAR ARRAYS (PORT and STBD)
HOUSING
SONAR ARRAYS (PORT and STBD)
