Edgetech 6205S - Figure 3-7: 6205 S Array Color Codes Diagram

3-22
The 6205s Arrays have been color-coded based on their operating frequency. The color code is shown and described below:
Figure 3-7: 6205s Array Color Codes Diagram
COLOR CODES
Color Code:
Blue = 230/550SS– 230 Bathy
Red = 230/550SS – 550 Bathy
Yellow = 550/850SS – 550 Bathy
Green = 550/1600SS – 550 Bathy
