6205s BATHYMETRIC AND SIDE SCAN SONAR 0020300_REV_E
8.4 SYSTEM RESTORE
This section outlines the procedures for backing up and restoring the optional EdgeTech supplied Laptop
crash. If the user experiences any issues, contact E
DGETECH CUSTOMER SERVICE immediately to help restore
the system and get the survey back up and running as soon as possible.
CAUTION!
All data will be lost upon restoring the system to factory settings. Be sure
to backup all data before performing the procedure below.
1. Ensure that the topside is off.
2. Insert USB3 flash drive in a blue USB3 port.
3. Start topside and be prepared to press a function key when prompted:
a. If the topside is rack mount, press F11.
b. If the topside is a laptop, press F12.
4. Under select boot device: By using up/down arrow keys, select EUFI: Corsair Voyager
3.0 000A, then press Enter.
5. Wait for Paragon Backup & Recovery 14 Home screen to appear, then click
Restore icon.
6. On Welcome to the Restore Wizard screen, click Next.
7. On Browse for Archive screen, drag down menu and click on ⊞ to the left of (E:). Click
on the folder named as a variation of V
⋆.⋆.⋆_⋆⋆⋆⋆R for rack mounts, or V⋆.⋆.⋆_⋆⋆⋆⋆P
for laptops. When the Archive File Details window appears, click Next.
8. At What to restore window, click Basic MBR Hard Disk 0, click Next.
9. At Where to restore window, ensure that Basic MBR Hard Disk 0 is already selected
(brown box around it). If it is not, use up/down arrow keys to select. Click Next.
10. At Restore results window, make no selection and click Next.
11. At the Ready to restore from the archive window, select ʘ Yes, apply the changes
physically. Click Next. Restoring will begin.
12. At Completing the restore wizard, click Finish. Click Shutdown.
13. Remove the USB3 flash drive and restart the topside.
