8-63
Figure 8-18: Closing the System Status Window
12. On the right-hand side of the window, click on the Config bullet under Update Button (green
arrow in F
IGURE 8-18) and then on the dropdown menu named Config Item (green arrow FIGURE
8-18).
13. Select Serial and then click on the Update button several times (blue arrow in F
IGURE 8-18).
14. Check to ensure the sensor's usage percentage is well below 80% (marked by a purple box).
a. If it is not, increase the baud rate of the sensor. Change the baud rate under Serial Port
Information, as shown in step 10. Check the Status again. Otherwise, the sonar will report
errors.
15. When satisfied with the incoming data, press OK in the System Status window, as shown in F
IGURE
8-18.
16. Finally, close the Sonar - 192.9.0.101 - Remote Desktop Connection window.
NOTE: If this window is left open during data acquisition, the user may
experience a very slow computer. This is because the remote desktop
application uses a large amount of the link capacity to stay open. So it is
