3-18
6205s BATHYMETRIC AND SIDE SCAN SONAR 0020300_REV_E
• 500GB Hard Drive
• 3 USB Ports
• 1 Ethernet Port
• 1 GB Graphics Card
The 6205s-Portable has an optional Ruggedized GETAC Laptop, preloaded with EdgeTech’s Discover
Bathymetric Software and all supporting software. The laptop has the specifications below:
• Windows 10 Professional Operating System
• Intel® Core™ i7-8650U vPro 1.9GHz processor with Turbo Boost Technology
• 8 GB of Memory (RAM)
• 1TB Hard Drive
• Intel UHD Graphics 620
• NVIDIA Quadro M2000M (4GB GDDR5)
• 3 USB 3.0 (9-pin)
• 1 USB 2.0 (4-pin)
• 1 Ethernet RJ45 Port
• 1 Mini Display Port1 HDMI Port
CAUTION! Installing additional software outside the provided EdgeTech
and third-party bathymetric software is NOT recommended. Installing
software other than those supplied can have undesirable effects, such as
poor and/or slow performance when acquiring Bathymetry and dual-
frequency Side Scan data. A list of approved third-party packages is
provided in THIRD-PARTY SOFTWARE.
3.7 Deck Cable
The deck cable is a 20 meter (65 ft) underwater, high-speed network data and power cable. The deck cable
includes Cat 5e 4-pair stranded conductors that meet or exceed TIA 568-B and is suitable for 10Base-T and
100Base-T. The deck cable is terminated with a Subconn 16 pin wet mate connector on both ends, has a
breaking strength of 545 kg (1200 lbs), and provides power and telemetry to 6205s Sonar Head.
CAUTION! DO NOT use Deck Cables for towing.
