6205s BATHYMETRIC AND SIDE SCAN SONAR 0020300_REV_E
SPECIFICATIONS
This section details the 6205s system specifications.
3.1 Physical Specifications
PHYSICAL
Size
Without Adapter Flange:
75.9 L x 24.4 W x 20.8 H cm
(29.8 L x 9.6 W x 8.2 H in)
With Adapter Flange:
75.9 L x 24.4 W x 25.5 H cm
(30 L x 9.6 W x 10.1 H in)
Weight
Without Adapter Flange:21.3 kg (47 lbs)
With Adapter Flange:25.9 kg (57.1 lbs)
Construction
Polycarbonate / 316 Stainless Steel Frame
Color
Blue Angels Yellow
Sealing
O-Ring Seal with Purge Valve
Table 3-1: Physical Specifications
3.2 Acoustic Specifications
SONAR HEAD
MODEL
230/550 KHZ SS – 230/550 BATHY 550/1600 SS - 550 KHZ BATHY
SIDE SCAN SONAR
Center Frequency
230/520 kHz
520/1610 kHz
Range (per Side)
225/125 m (738/410 ft)
125/35m (410/115 ft)
Range Resolution
30/15 mm (1.18/0.4 in)
15/6 mm (0.4/0.2 in)
Beam Width Along
Track
0.64°/0.47° (2-way)
0.47°/0.2° (2-way)
Depression Angle
35°
35°
SWATH BATHYMETRY
Center Frequency
230 kHz/520kHz
520 kHz
Maximum Swath
350 m (1148 ft)
150 m (492 ft)
Beam Width Along
Track
0.64°/0.47°
0.47°
Ping Repetition
Rate
(Both Sides
Simultaneously)
15 m (16 ft) = 50 Hz
25 m (82 ft) = 30 Hz
50 m (164 ft) = 15Hz
100 m (328 ft) = 8 Hz
200 m (656 ft) = 4 Hz
5 m (16 ft) = 150 Hz
25 m (82 ft) = 30 Hz
50 m (164 ft) = 15 Hz
100 m (328 ft) = 8 Hz
150 m (492 ft) = 5 Hz
BATHYMETRY
