8-68
6205s BATHYMETRIC AND SIDE SCAN SONAR 0020300_REV_E
7. Check COM1 and set the correct baud rate for that device using the dropdown menu shown in
blue, as shown in F
IGURE 8-16. When the correct baud rate is set, the State should say OK, and
Errors should not be increasing, as shown in F
IGURE 8-16, circled in green. The correct data string
should also be scrolling in the lower part of the window, as shown in F
IGURE 8-16, green arrow.
8. Check COM2 and set the correct baud rate for the other device as done before in Step 6.
a. Remember to check COM3 as before and set the correct baud rate for GPS.
9. Click on File > Show Status in the sonar window, as shown in
FIGURE 8-17, circled in red.
10. On the right-hand side of the window, click on the Config bullet under the Update button, and
then on the dropdown menu named Config Item, as shown by the green arrow in
FIGURE 8-18.
11. Select Serial (green arrow), then click on the Update button several times (blue arrow) in F
IGURE
8-18.
12. Check to make sure sensors' usage percentages are well below 80%, as shown in
FIGURE 8-22,
circled in purple. If they are not, increase the sensor’s baud rate. Change baud rate under Serial
Port Information as done in steps 6 and 7. Check Status again; otherwise, sonar will report errors.
13. When satisfied with incoming data, press OK in the ‘System Status’ window, as shown in
FIGURE 8-
18.
14. Finally, close the Sonar - 192.9.0.101 - Remote Desktop Connection window.
NOTE: If this window is left open during data acquisition, the user may
experience a very slow computer. This is because the remote desktop
application uses a large amount of the link capacity to stay open. So it is
always a good idea to close the remote desktop application when finished
with the configurations.
