Edwards STP Series User Manual

STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 102
5
SERIAL COMMUNICATION PROTOCOL
5.4.7 ReadCounters
Function: Reads serial number, hour counter and start counter.
Transmission frame:
PC->SIM Stx 0 0 1 ? c Etx LRC
SIM->PC Ack
PC->SIM Ack
SIM->PC Stx 0 0 1 Sp c Parameter 1 to 23 Etx LRC
Parameter Item Data format Remarks
1 to 10 Control unit serial number 4-bits ASCII character
11 to 20 Pump serial number 4-bits ASCII character
21 Pump hour counter
(Unit: minute)
32-bits hexadecimal
coded ASCII
22 Control unit hour counter
(Unit: minute)
32-bits hexadecimal
coded ASCII
23 Start counter 32-bits hexadecimal
coded ASCII
Example:
Control unit serial number : 12345
Pump serial number : 6789A
Pump hour counter : 0000003C
hex
= 60 minutes = 1 hour
Control unit hour counter : 0000028C
hex
= 652 minutes =10 hours and 52 minutes
Start counter : 00000064
hex
= 100 times
Parameter 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
ASCII 1 2 3 4 5 6 7 8 9 A
HEX 31 32 33 34 35 20 20 20 20 20 36 37 38 39 41 20 20 20 20 20
Parameter 21 22 23
ASCII 0 0 0 0 0 0 3 C 0 0 0 0 0 2 8 C 0 0 0 0 0 0 6 4
HEX 30 30 30 30 30 30 33 43 30 30 30 30 30 32 38 43 30 30 30 30 30 30 36 34
