STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 130
6
STP-LINK AND DISPLAY UNIT
6.2 Display unit
The "display unit" operates the STP pump, confirms the pump status or sets various settings. The
display unit iDT-001 is equipped with an LCD and flat panel switches.
See the Instruction Manual of the "Display unit iDT-001" for the detailed specification and operating
methods.
STP-Link
BRAKE
ACCEL.
STOP
START
NORMAL FAILURE
POWER
UP
DOWN ENTER
SELECTRESET
65
98.4
132
122.5
Figure 50 - Display unit iDT-001
