Edwards STP Series User Manual

STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 74
5
SERIAL COMMUNICATION PROTOCOL
5.2.4 Input operation port setting
Set the input operation port to the serial port when operating the STP pump via the serial port in
accordance with the following procedures.
1. Open the "PORT SELECT IN" signal between (1)-(4) of the "X2 REMOTE" connector.
If the pins are closed, the input operation port will be set to the parallel port automatically, and the
input operation via the serial port is disabled (refer to Section 4.9, "Parallel port input/output
signal" for the details of the "X2 REMOTE" connector).
2. Set the parameter of the "Input operation port" to the serial port which operates STP pump,
following Section 5.4.16. The parameter value of the factory setting is "I/O REMOTE" (parallel
port). The "Input Operation Port" can also be changed via the STP-Link (optional accessory).
Input operation
port
Remark
Parallel port I/O Remote X2 REMOTE connector
Serial port COM1 X3 COM1 connector
COM2 X4 COM2 connector, Profibus (optional accessory)
COM3 X5 STP-LINK connector
Table 22 - Input operation port
Note: Any commands other than STP pump operation are effective in every port regardless of the
input operation port setting.
