Edwards STP Series User Manual

STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 93
5
SERIAL COMMUNICATION PROTOCOL
5.4 Command specifications
5.4.1 Command list
Function
code
Command/Query Name Function
? D ReadMeas Reads the measured rotational speed.
Sp E Command Sends commands START, STOP, RESET (These
commands are valid only when being sent to the
serial port which is set as the input operation port.)
? F ReadFailMess Reads the errors being detected.
? M ReadModFonct Reads the pump operation mode and the errors
being detected.
? V ReadVersion Reads the software version.
? c ReadCounters Reads serial number, hour counter and start
counter.
? d ReadSetPoint
Reads the setting values of the speed set point and
the TMS temperature.
? e ReadMotorTemp Reads the measured motor temperature.
? f ReadStatus Reads the various settings.
(Remote mode, T
MS function, and emergency vent
valve).
? g ReadEvents Reads the error record.
Sp h SetSpeedSetPoint Changes the speed set point.
? h ReadSpeedSetPoint Reads the speed set point.
? m ReadModFonctWithWarning Reads the pump operation mode, the errors and
the warnings being detected
? [ ReadMeasValue Reads the TMS temperature, motor temperature,
motor current, measured rotational speed, and
control unit temperature.
? = ReadOptionFunc Reads each setting value of items
Sp = SetOptionFunc Changes each setting value of items
? { ReadCondition Reads pump model and damage point
? } ReadEventsWithTime Reads the error record with detection
time
Bsp 0 SetOptions Changes optional function (Second speed option)
? 0 ReadOptions Reads optional function (Second speed option)
Table 26 - Command list
