STP-iXR1606
Tu
rbomolecular
Pump
MT-79E-001-D
Page
38
INSTALLATION
3
3.4.4
Legs
for
securing
the
base
CAUTION
W
hen
securing
the
base,
use
stainless
s
teel
securing
bolts
with
a
tensi
le
strength
class
is
70
or
more.
Figure
22
sho
ws
the
position
of
the
four
s
crew
holes
fo
r
securing
the
base.
Figure
22
-
Scre
w
holes
for
securing
the
base
M8
Depth
20
mm
47
49
