Edwards STP Series User Manual

STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 119
5
SERIAL COMMUNICATION PROTOCOL
Example:
1. Pump model:
5354502D6958523136303620202020202020202020
hex
= STP-iXR1606
3. Damage point: 32
hex
= 50
Parameter 1
"S" "T" "P" "–" "i" "X" "R" "1" "6" "0"
ASCII
5 3 5 4 5 0 2 D 6 9 5 8 5 2 3 1 3 6 3 0
HEX
35 33 35 34 35 30 32 44 36 39 35 38 35 32 33 31 33 36 33 30
Parameter 1
"6" " " " " " " " " " " " " " " " " " "
ASCII
3 6 2 0 2 0 2 0 2 0 2 0 2 0 2 0 2 0 2 0
HEX
33 36 32 30 32 32 32 30 32 30 32 30 32 30 32 30 32 30 32 30
Parameter 2 3 4
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
0 0 3 2
*1
*1
*1
*1
*1
*1
*1
*1
HEX
30 30 33 32
Parameter 4
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
HEX
*1 System reservation
