STP-iXR1606 Turbomolecular Pump
MT-79E-001-D
Page 42
INSTALLATION
3
CAUTION
DO NOT place heavy objects on the cables or bend them excessively. Support each cable so as
not to apply direct force to the connectors or terminals. If any problem occurs in cables, connectors
or terminals, the STP pump may not function normally. DO NOT apply voltage to each connector
pin and DO NOT cause any short-circuiting between pins. Install cables so that personnel are not
exposed to risk of tripping or falling.
Connect the power cable to the "X1 AC POWER" on the control unit front panel.
To Next Page
