Ekra E1 - Page 127

Electrical Parts List 2499000127
Control E1
Date of
design:
01.03.2002 Date of change: 12.04.2002 Circuit
diagram:
E1_006
# Article description Order no.
Seite/Page 1
© EKRA
30.08.02
A3 Frequency converter 0.9kVA 230V 5382000007
A3.1 Soldering terminal MP12 (12paired transition) 5360000055
A4.1 Overvoltage load module 5382000006
Basic module Mounting basic module 5399000004
D11 Diode 1N4007 5375000001
D11.1 Diode 1N4007 5375000001
D2 Diode 1N4007 5375000001
D2.1 Diode 1N4007 5375000001
D3 Diode 1N4007 5375000001
D3.1 Diode 1N4007 5375000001
D4 Diode BY251(2A) 5375000006
D5 Diode BY251(2A) 5375000006
F2 Fuse 5*20mm T4.0A 250V
Series terminal M4/8.SF gray with fuse clip
5357000002
5360000058
F3 Automatic cut-out 1pole C6A 5357000029
for foot switch S6 Cable Ölflex-110 2*1.0mm² 5361000021
for MOPS 3pin mini coupling socket M8 with cable 6m 5360000091
for power line Cable Ölflex-110 3G*1.5mm² 5361000020
K1 Mini relay 24V with 4 change-over contacts
Socket for plug-in relay
5350000004
5350000005
K4 Mini relay 24V with 4 change-over contacts
Socket for plug-in relay
5350000004
5350000005
Q1 Main switch 3pole, 400V, 4kW, for front mounting
Cable Ölflex-110 5G*1.5mm²
5353000005
5361000027
R1 Resistor 470 Ohm 5% 0.25W Baugr. 0207 5373000001
R2 Resistor 1.8k Ohm 5% 0.25W Baugr. 0207 5373000002
S01 Front element Emergency Stop push-button Q25PV
Auxiliary switch 1 NC E01
Plate EMERGENCY STOP square-type, in 4 languages
Cable Ölflex-110 3G*0.5mm²
5353000015
5353000016
5353000017
5361000018
S11 Selector switch front element with actuator, 3 switch
positions
Auxiliary switch 1 NO + 1 NC for panel mounting
Cable Ölflex-110 5G*0.5mm²
5353000012
5353000013
5361000019
T1 Power supply 230V / 24V 2A 5321000003
X1 Series terminal M4/6 gray
Series terminal M4/6.P green/yellow
5360000056
5360000057
X6 25pin Sub-D socket with 2.3m LIYY 10*0.14 with housing 5360000140
