Electrical Parts List 2499000128
Machine E1
Date of
design:
01.03.2002 Date of change: 12.04.2002 Circuit
diagram:
E1_006
# Article description Order no.
Seite/Page 1
© EKRA
30.08.02
A4 Analogue power controller 5382000005
En4 Encoder 5355000003
for M3 Cable Ölflex-110CY 4G*1.5mm² with shield 5361000092
for M4 Cable Ölflex-110 3G*1.5mm² 5361000020
for M4.1 Cable Ölflex-FD810 7G*0.5mm² 5361000034
for key pad Cable 37*?mm², L= 2m 5361000010
S02 Safety switch 1 NC + 1 NO with switch cam
Cable Ölflex-110 4*1.0mm², 3.5 m
5353000019
5361000009
S03 Position limitation switch 1NO + 1NC with roller tappet,
moulded case
Cable Ölflex-110 4*1.0mm², 1.60m
5353000009
5361000009
S04 Safety switch 1 NC + 1 NO with trip cam
Cable Ölflex-110 4*1.0mm², 2.60m
5353000019
5361000009
S10 Inductive proximity switch 5355000002
S13 Micro switch 6A (1005.0401)
Cable Ölflex-FD810 7G*0.5mm²
5353000007
5361000034
S14 Micro switch 6A (1005.0401)
Cable Ölflex-FD810 7G*0.5mm²
5353000007
5361000034
S2 Inductive proximity switch 5355000002
S2.1 Inductive proximity switch 5355000002
S3 Inductive proximity switch 5355000002
S3.1 Inductive proximity switch 5355000002
S4 Inductive proximity switch 5355000002
S5 Inductive proximity switch 5355000002
S6 Pedal switch 5353000006
Tastatur Key pad with LCD display 5353000014
X0 Safety plug 16A 250VAC, vertical side cable entry 5360000081
X7 Multiple socket-outlet with earthing contact 5360000060
