Ekra E1 - Page 75

Parts List 2223000003
Table lifting drive E1
Date of
design:
23.03.2001 Date of change: 20.04.2001 Drawing
77657F
Variation:
Item Var. Quant. Designation Dimension Article
10
1,00
piece
plate 15*220*500 4052000061
20 4,00
piece
plate 50*12*164 4052000062
30 2,00
piece
shaft 30h6*310 4036000006
40 2,00
piece
lever 60*25*120 4053000057
50 1,00
piece
shaft 4036000007
60 4,00
piece
excenter 40*40*74 4053000058
70 4,00
piece
bolt 25*63 4034000005
80 4,00
piece
washer 60*24 4030000012
90 4,00
piece
shaft 25h6*234 5031140008
100 2,00
piece
attachement 120*15*468 4052000063
110 6,00
piece
base 60*2*60 4044000003
120 1,00
piece
plate 420*15*610 4052000064
130 4,00
piece
bearing 80*140 4057000004
140 4,00
piece
bush 40*5*16 4038000004
200 1,00
piece
angle L80*64*8*200 4056000043
210 1,00
piece
pneumatic-connection Sk13*18 4039000004
220 1,00
piece
angle L80*80*8*181 4056000044
230 1,00
piece
holder 36*35*60 4053000059
240 1,00
piece
treaded rod (right) M16*1*175 4033000008
Seite/Page 1
© EKRA
10.04.02
