Ekra E1 - Page 76

Parts List 2223000003
Table lifting drive E1
Date of
design:
23.03.2001 Date of change: 20.04.2001 Drawing
77657F
Variation:
Item Var. Quant. Designation Dimension Article
250
1,00
piece
bearing 40*40*45 4057000005
260 1,00
piece
ledger 24*20*44 4053000060
270 1,00
piece
angle L30*20*3*14 4056000045
280 1,00
piece
shaft 6h6*125 4036000008
290 1,00
piece
guidance 26*15*54 4054000029
300 1,00
piece
angle L100*30*5*30 4056000046
310 1,00
piece
washer 4030000013
320 1,00
piece
bush M10*M6*10 4034000006
330 1,00
piece
angle L40*30*3*125 4056000047
340 1,00
piece
treaded rod TR10*3*330 4033000009
350 3,00
piece
slide DIN 705-A10 zinced 5014000004
360 1,00
piece
motor plate 120*10*106 4052000065
370 1,00
piece
washer 28*5 4030000014
380 1,00
piece
shaft 30h6*145 4036000009
390 1,00
piece
synchronous washer 31T10/24-2 5011150021
400 1,00
piece
washer 40*6 4030000015
410 1,00
piece
synchronous washer 31T10/24-2 5011150022
420 1,00
piece
axis 15h6*64 4037000002
430 1,00
piece
angle L60*54*10*40 4056000048
