Ekra E1 - Page 77

Parts List 2223000003
Table lifting drive E1
Date of
design:
23.03.2001 Date of change: 20.04.2001 Drawing
77657F
Variation:
Item Var. Quant. Designation Dimension Article
440
2,00
piece
pressure piece 10*12 4039000005
450 2,00
piece
ledger 80*12*80 4053000061
460 1,00
piece
support 15*8*100 4054000030
470 1,00
piece
plate 20*8*34 4052000066
480 1,00
piece
plate 20*8*34 4052000067
490 1,00
piece
limited 24*15*165 4054000031
500 4,00
piece
angle L30*30*3*40 4056000049
510 1,00
piece
holder 25*10*30 4053000062
520 1,00
piece
angle L80*40*6*40 4056000050
530 1,00
piece
push botton 50*12*160 4054000032
540 1,00
piece
bolt NLM 02010-061 5054000002
550 1,00
piece
metering clockwork 30mm M2/30 T 5028000001
560 1,00
piece
synchronus belt 16T10*1450-V 5011100013
570 2,00
piece
groove ball bearing DIN 625-6202
D15*35*11 with 2 cover disk
5013000008
580 1,00
piece
worm gear pair motor NMS40-HU-7.5/1 5310040001
590 1,00
piece
frequency converter 0.9kVA 230V 5382000007
600 2,00
piece
linear guidance Bgr.25 SSR
25XWY2UU+940LY
5031080010
610 8,00
piece
guide bush compact 25*58 5031120006
620 4,00
piece
support roll D=32 d=12 B=15 5013230003
Seite/Page 3
© EKRA
10.04.02
