Ekra E1 - Page 80

Parts List 2230000003
Printing table E1
Date of
design:
27.03.2001 Date of change: 11.09.2001 Drawing
77735E
Variation:
Item Var. Quant. Designation Dimension Article
10
3,00
piece
handle 35*35 4039000006
20 3,00
piece
flange 65*45 4039000007
30 2,00
piece
adjustable spindle left-hand thread M16*1*75 4033000010
40 3,00
piece
bush 24*12 4030000008
50 1,00
piece
adjustable spindle left-hand thread M16*1*200 4033000011
60 3,00
piece
pressure piece 23*45 4039000008
70 2,00
piece
spring support 30*40 4039000009
80 4,00
piece
block 55*55*30 4053000067
90 1,00
piece
print plate 28*5*65 4052000077
100 1,00
piece
bush 24*12 4030000008
110 1,00
piece
frame Profil*590 4010000036
120 1,00
piece
frame Profil*450 4010000037
130 1,00
piece
frame Profil*590 4010000038
140 1,00
piece
frame Profil*450 4010000039
150 1,00
piece
metal strip 12*0.3*60 4044000004
160 1,00
piece
rectangular tube 30*30*3*540 4010000044
170 1,00
piece
table plate E1 443*15*583 4052000078
180 1,00
piece
lever 140*15*149 4052000079
190 1,00
piece
plate 40*6*70 4052000080
Seite/Page 1
© EKRA
10.04.02
