Ekra E1 - Page 81

Parts List 2230000003
Printing table E1
Date of
design:
27.03.2001 Date of change: 11.09.2001 Drawing
77735E
Variation:
Item Var. Quant. Designation Dimension Article
200
1,00
piece
bolt 12h6*38 4034000008
210 1,00
piece
angle L20*20*3*44 4056000055
220 600,00
mm
energy chain series 06 E2 B=16.5 R=28
black
5090010005
230 1,00
piece
connection element series 06 E2 B=16.5 5090110004
240 4,00
piece
T-sliding block DIN 508-M6*8 5051000001
250 7,00
piece
ball caster without bond da=22 H=17.5
h=5.5
5013210002
260 2,00
piece
spring DIN 2098-2.50*12.50*67.5 5023000005
270 2,00
piece
DU-collar bushing (H) 12*14*20*7 5012070004
280 6,00
piece
ball roll with bond da=24 H=21.5 h=9.5 5013210003
290 8,00
piece
disc spring DIN 2093 39.6*25.5*0.4 5023300002
300 1,00
piece
holder 40*10*450 4054000039
310 2,00
piece
distance 30*68 4038000011
330 1,00
piece
spring support 24*38 4038000012
340 3,00
piece
pressure piece 30*15*40 4053000071
Seite/Page 2
© EKRA
10.04.02
