Ekra E1 - Page 85

Parts List 2210000003
Upper part E1
Date of
design:
18.04.2001 Date of change: 18.04.2001 Drawing
77843F
Variation:
Item Var. Quant. Designation Dimension Article
10
2,00
piece
angle L60*60*6*875 4056000063
40 2,00
piece
bearing block 4057000006
60 2,00
piece
instep block 12*10*40 4053000030
70 2,00
piece
bearing bolt 50*36 4057000002
80 2,00
piece
plate 40*6*155 4052000093
90 2,00
piece
clamp ledge 70mm 40*8*70 4054000046
100 1,00
piece
drive shaft 20H6*680 4036000015
110 1,00
piece
square for the motor L80*80*8*90 4056000064
140 1,00
piece
plate 55*5*50 4052000094
160 1,00
piece
belt stretcher 50*15*70 4052000095
200 1,00
piece
square angle pipe 30*15*2*450 4010000046
210 1,00
piece
sensor holder 20*4*70 4052000096
220 1,00
piece
coupling 15*27 4039000010
230 1,00
piece
holder U50*50*4*50 4010000047
350 2,00
piece
synchronous belt 16T10*1880 5011100014
360 1,00
piece
synchronous belt 124L/100 neopren 5011100015
370 4,00
piece
groove ball bearing DIN 625-6001
D12*28*8 with 2 cover disk
5013000004
380 2,00
piece
synchronous washer 31T10/16-2 5011150013
390 2,00
piece
synchronous washer 31T10/16-2 5011150010
Seite/Page 1
© EKRA
10.04.02
