Ekra E1 - Page 86

Parts List 2210000003
Upper part E1
Date of
design:
18.04.2001 Date of change: 18.04.2001 Drawing
77843F
Variation:
Item Var. Quant. Designation Dimension Article
400
2,00
piece
housing unit DW=20 5013080001
410 4,00
piece
shaft bracket 1055 für shaft d=16 5031180001
420 2,00
piece
shaft 16h7*764 5031140010
430 2,00
piece
shaft support for shaft d=16, L=30 4010000018
460 1,00
piece
synchronous washer 14L100 5011150023
470 1,00
piece
DC gear motor d=63, 24V, i=64:1 5310020006
480 1,00
piece
synchronous washer 14L100 5011150024
490 4,00
piece
guide bush 16*36 5031120005
510 2,00
piece
Polyurethan-spiral hose L=1.5m 5671000003
Seite/Page 2
© EKRA
10.04.02
