13
1.3 Installation
1 Installation Conditions
󳜪Use the product in the following conditions.
Temperature
0󳟻40󳇾
Humidity
20󳟻80󳞣
󳜪To prevent internal heat buildup, install the display monitor in a well-ventilated place, keeping the
distance as specified in the following figure from the surrounding area.
Use the following screws to attach the VESA brackets.
For EL65R2󳜪EL75R2󳜪EL86R2: M8 screws with a length of 20 mm
For EL55R2: M6 screws with a length of 20 mm
Caution
Since the display monitor is heavy, consult the dealer from whom you purchased
this product when installing, removing or moving it.
Installation must be done by professional service engineers. Otherwise, injury may
occur by improper installation.
If you want to mount the display monitor on a wall or suspend it from the ceiling,
ask a specialist for installation work.
ELMO is not responsible for any accident or damage caused by improper installation.
If you need to move the display monitor after it is attached to the stand, always
move the product with 2 or more people.
Be careful not to block the ventilation holes when installing. The heat will be
trapped inside and may cause a malfunction or a fire.
Do not install the display monitor in a place where it may be exposed to rain or
spray, or in a place with high humidity.
Do not install the display monitor near the air outlet of the air conditioner.
Condensation may form due to sudden temperature changes, which may corrode the inside
and cause a malfunction.
30cm
Wall
30cm
30cm
30cm
10cm
