Elmo L-12W User Manual

iv
SA 1965
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
SA 1966
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection
of waste electrical and electronic equipment in the EU countries.
Please do not throw the equipment into the domestic refuse.
Please use the return and collection systems available in your country for the
disposal of this product.
CAUTION
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE
PA RTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.

Elmo L-12W Specifications

General

AC input voltage	100 - 240 V
Operating voltage	12 V
Power supply type	DC
Power consumption (typical)	5 W
Interface	USB 2.0
DC-in jack	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB connector type	USB Type-A, USB Type-B
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Image formats supported	JPG
Maximum operating distance	0.2 m
Compatible memory cards	SD
Sensor type	CMOS
Maximum frame rate	30 fps
Effective sensor resolution	6.7 MP
Supported graphics resolutions	2992 x 2244, 3264 x 2448
Digital zoom	16 x
Optical zoom	12 x
Shooting area (WxD)	470 x 260 mm
Maximum focal length (f)	3.6 mm
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	377 mm
Width	349 mm
Height	432 mm
Weight	3000 g
Dimensions folded (WxDxH)	195 x 294 x 475 mm
