Express Install for File OE release 7.0 or lower
205
NAS Install Options
EMC CONFIDENTIAL
9. The Primary Internal Network Setup window appears (Figure 113). Enter the
Control Station internal networking configuration information from the values in
the “Control Station 0 networking worksheet” on page 277:
Note: Unless there is a conflict with the customer’s existing network, you should use the
default private LAN IP addresses. If you use other addresses, you must still use the last
octet of the default address. You cannot change the hostname values.
a. In the Primary Internal Network Setup dialog box, enter the IP address and
netmask for the primary internal LAN connection (port A) (Figure 113). To
accept the default values, tab to Ok and press Enter.
Figure 113 Primary internal network settings
The system displays the IPMI Network Setup dialog box (Figure 114 on
page 206).
b. Enter the IP address and netmask for the IPMI connection (CS ports) between
two Control Stations (Figure 114 on page 206). To accept the default values, tab
to Ok, and press Enter.
