EMC VNX VG2/VG8 Gateway Configuration Setup Guide
308
Navisphere Manager procedures
EMC CONFIDENTIAL
4. In the Selected LUNs box, select each LUN and set its Host ID, as shown in
Figure 181 on page 308. Clicking a value in the Host ID column gives you a list of
available HLUs.
It is critical that you match the LUN capacity with the correct Host LUN values.
Set the Host LUN (HLU) values as shown in Table 19:
Table 19 Host LUN capacities
5. Click OK.
Figure 181 Storage Group Properties dialog box
Capacity Host LUN (HLU)
11.000 GB 0
11.000 GB 1
2.000 GB 2
2.000 GB 3
2.000 GB 4
64.000 GB 5
