EMC VNX VG2 User Manual

Step 1: Check components
37
Before Installing
EMC CONFIDENTIAL
Figure 6 shows the rear view of an VG2 blade enclosure with two blades and two
Control Stations. The right blade in the enclosure has the lower blade number. For
example, in the blade enclosure, blade 2 is on the right and blade 3 is on the left. Each
blade can have from one to four I/O modules (the last slot contains an I/O filler
panel). A mix of different I/O module types is possible.
Figure 6 Example of VNX VG2 system—two blades and two CSs (rear)
Figure 7 shows the front view of the same system shown in Figure 6.
Figure 7 Example of VNX VG2 system—two blades and two CSs (front)
Serial
console
MGMT
CS
B
MODEM plug
VGA socket
A
0
123
0
123
0
12 3
0
1 23
0
1 23
0
1 23
0
1 23
0
1
23
0
12 3
0
12 3
Serial
console
MGMT
CS
B
MODEM plug
VGA socket
A
Control Station 1
Blade 3
Control Station 0
CNS-001641 Blade 2
DVD
DVD
Control Station 1
AC
AC
AC
AC
Control Station 0
CNS-001655
