5.5.3 Keypad (EDP IW 100-242-560; EDP IW+ 100-242-561)
5.5.3.1 Removing the Keypad
1. Turn off the welder and unplug main power.
2. Turn air pressure to zero, then disconnect main air supply.
3. Open the left side cover. See Section
5.3 Opening and Removing the Left Side Cover (EDP 100-
032-338).
4. Remove the nose assembly (Section
5.5.1 Removing the Nose Assembly).
5. Unplug the Keypad cable connector (P30) from the Control Module (
5.5.3.1 Removing the
Keypad).
6. Peel the Keypad off the nose cover (
5.5.3.1 Removing the Keypad).
7. Pull the Keypad cable through the nose cover.
8. Remove any adhesive remaining on the nose cover.
WARNING General Warning
Turn air pressure to zero and disconnect the main air supply. Failure
to do this leave the welder under potentially dangerous air pressure.
