Example No. 1 Table
Output Table
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Valve Coil
No. 7
Valve Coil
No. 6
Valve Coil
No. 5
Valve Coil
No. 4
Valve Coil
No. 3
Valve Coil
No. 2
Valve Coil
No. 1
Valve Coil
No. 0
1
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Valve Coil
No. 11
Valve Coil
No. 10
Valve Coil
No. 9
Valve Coil
No. 8
2
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
3
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Input Table
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
(Optional)
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
Comm. Module
Diagnostic Bit
1
(Optional)
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
2
(Optional)
Coil No. 7
Status
Coil No. 6
Status
Coil No. 5
Status
Coil No. 4
Status
Coil No. 3
Status
Coil No. 2
Status
Coil No. 1
Status
Coil No. 0
Status
3
(Optional)
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Coil No. 11
Status
Coil No. 10
Status
Coil No. 9
Status
Coil No. 8
Status
4
(Optional)
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
5
(Optional)
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
6
Discrete Input
No. 7
Discrete Input
No. 6
Discrete Input
No. 5
Discrete Input
No. 4
Discrete Input
No. 3
Discrete Input
No. 2
Discrete Input
No. 1
Discrete Input
No. 0
7
Discrete Input
No. 15
Discrete Input
No. 14
Discrete Input
No. 13
Discrete Input
No. 12
Discrete Input
No. 11
Discrete Input
No. 10
Discrete Input
No. 9
Discrete Input
No. 8
8
(Optional)
Power Status for
Conn. H
Power Status for
Conn. G
Power Status for
Conn. F
Power Status for
Conn. E
Power Status for
Conn. D
Power Status for
Conn. C
Power Status for
Conn. B
Power Status for
Conn. A
9
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog Input
No. 1 (LSB)
10
Analog Input
No. 1 (MSB)
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
11
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog Input
No. 2 (LSB)
12
Analog Input
No. 2 (MSB)
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
13
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog Input
No. 3 (LSB)
14
Analog Input
No. 3 (MSB)
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
15
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog Input
No. 4 (LSB)
16
Analog Input
No.4 (MSB)
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
17
(Optional)
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Power Status for
Conn. D
Power Status for
Conn. C
Power Status for
Conn. B
Power Status for
Conn. A
18
(Optional)
High Alarm for
Conn. D
Low Alarm for
Conn. D
High Alarm for
Conn. C
Low Alarm for
Conn. C
High Alarm for
Conn. B
Low Alarm for
Conn. B
High Alarm for
Conn. A
Low Alarm for
Conn. A
• The Comm. Module Diagnostic Bits, Sub-Bus Diagnostic Bits, Coil Status Bits and
Power Status Bits are optional. The factory default condition is Diagnostic bits
enabled. These bits may be disabled to optimize the logical size of the manifold.
NOTE!
