Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
15-172
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
Manifold I/O Configuration
Pos.
No.
Module Type Part No.
In
Out
Bytes
Diagnostic Word
2
0
Local Valve Size:
4
4
Total: 6 4
How to Order
Qty
Part Number
1
8502AV3F300VA00
2
R502A1B10MA00F1
1
K502AMM22MA0010
1
R502A1B10MA00F1
1
R502A1B40MA00F1
1
K502AMM22MA0010
2
R502A1B40MA00F1
1
K502AMM22MA0010
1
G3EC100R0E44
ASSEMBLED
Assumed Settings
Example No. 2
a. Double Z-Boards
TM
used with all valves
b. I/O Modules and mapping schemes are
identified by their corresponding color.
c. I/O Status bits are enabled
d. Diagnostic Word is enabled
When the 14 End
Solenoid is
energized, the 4 port
is pressurized
When the 12 End
Solenoid is
energized, the 2 port
is pressurized
0
2
4
6
8
10
1
3
5
7
9
11
Valve Coil
Number
