One Analog I/O per Connector – M12 Female Modules
Output Mapping
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
(LSB)
X+1
Output
No. 1
(MSB)
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
Output
No. 1
X+2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
(LSB)
X+3
Output
No. 2
(MSB)
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Output
No. 2
Input Mapping
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1 (LSB)
X+1
Input No.
1 (MSB)
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
Input No.
1
X+2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2 (LSB)
X+3
Input No.
2 (MSB)
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Input No.
2
Diagnostic Telegram
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X
(Selectabl
e)
Allocated
and
Reserved
Allocated
and
Reserved
Allocated
and
Reserved
Allocated
and
Reserved
SCP
Status for
Conn. D
SCP
Status for
Conn. C
SCP
Status for
Conn. B
SCP
Status for
Conn. A
X+1
(Selectabl
e)
High
Alarm for
Conn. D
Low Alarm
for Conn.
D
High
Alarm for
Conn. C
Low Alarm
for Conn.
C
High
Alarm for
Conn. B
Low Alarm
for Conn.
B
High
Alarm for
Conn. A
Low Alarm
for Conn.
A
Module
Part No.
Signal Type
Short Circuit
Protection
Short Circuit
Protection Status
Bits
Output
Points Input Points
240-213
0-10 VDC
YES YES 2 2
240-215
4-20 mA
