Emerson E300 Series User Manual

Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
User Menu
A
Commissioning
Advanced
Parameters
Diagnostics Optimization CT MODBUS RTU Technical Data
E300 Design Guide 123
Issue Number: 1
Table 6-2 User Menu A Open loop, RFC-A and RFC-S parameters
Parameter
Range(Ú)Default(Ö)
Type
OL RFC-A RFC-S OL RFC-A RFC-S
A00 Parameter {A00} 0 to 65535
RW Num ND NC PT
A01 User Security Status {H02}
User Menu A (0), All Menus (1),
Read-only User Menu A (2), Read-only (3),
Status Only (4), No Access (5)
RW Txt ND PT
A02 Drive Control Mode {B01} Open loop (1), RFC-A (2), RFC-S (3)
Open
loop (1)
RFC-A
(2)
RFC-S
(3)
RW Txt ND NC PT
A03 Parameter Cloning {N01}
None (0), Read (1), Program (2),
Auto (3), Boot (4)
None (0) RW Txt NC US
A04 Total Output Current {J22}+
VM_DRIVE_CURRENT_UNIPOLAR A RO Num ND NC PT FI
A05 Percentage Load {J23}+
VM_USER_CURRENT % RO Num ND NC PT FI
A06
Profile Speed {J39} 0 to 10000 mm/s
RO Num ND NC PT
Actual Speed {J40}
0 to 10000 mm/s RO Num ND NC PT
A07 Output Power {J59}+
VM_POWER kW RO Num ND NC PT FI
A08 Output Frequency {J60}
+
VM_SPEED_
FREQ_REF Hz
+
550.0 Hz RO Num ND NC PT FI
A09 Output Voltage {J61}+
VM_AC_VOLTAGE V RO Num ND NC PT FI
A10 Control Input Mode {H11}
Analog Run Prmit (0), Analog 2 Dir (1),
Priority 1 Dir (2), Binary 1 Dir (3),
Priority 2 Dir (4), Binary 2 Dir (5),
Control Word (6)
Priority 1 Dir (2) RW Txt US
A11 Direction Input Invert {H12} Off (0) or On (1) 0ff (0) RW Bit US
A12 Drive Encoder Type {C01}
AB (0), FD (1), FR (2),
AB Servo (3), FD Servo (4),
FR Servo (5), SC (6),
SC Hiperface (7),
EnDat (8), SC EnDat (9),
SSI (10), SC SSI (11),
SC Servo (12), BiSS (13),
SC SC (15),
Commutation Only (16)
AB (0)
AB
Servo
(3)
RW Txt US
A13
Drive Encoder Auto
Configuration Select
{C02}
Disabled (0)
or Enabled (1)
Enabled (1) RW Txt US
A14
Drive Encoder
Rotary Pulses Per
Revolution
{C03}
1 to 100,000 ppr
1024
ppr
4096 ppr RW Num US
A15
Drive Encoder
Voltage Select
{C04}
5 V (0), 8 V (1), 15 V (2) 5V (0) RW Txt US
A16
Position Feedback
Phase Angle
{C13}
0.0 to 359.9 ° 0.0 °
RW Num ND US
Slip Compensation
Enable
{B10} Off (0) or On (1)
On (1) RW Bit US
A17
Drive Encoder
Feedback Reverse
{C12}
Off (0) or On (1) Off (0) RW Bit US
Low Frequency
Voltage Boost
{B12} 0.0 to 25.0 %
3.0 % RW Num US
A18 Motor Rated Current {B02}+
VM_RATED_CURRENT A
Maximum Heavy Duty Rating
(J05)
RW Num RA US
A19 Motor Rated Voltage {B03}+
VM_AC_VOLTAGE_SET V
200 V drive: 230 V
50 Hz - 400 V drive: 400 V
60 Hz - 400 V drive: 460 V
575 V drive: 575 V
690 V drive: 690 V
RW Num RA US
A20
Number Of Motor
Poles
{B05} Automatic (0) to 480 Poles (240) Automatic (0)
6 Poles
(3)
RW Txt US
