Emerson Rosemount 3100 Series Reference Manual

110
Appendix D: Rosemount 3490 Series Menus February 2015
Reference Manual
00809-0100-4840, Rev CB
Rosemount 3490 Series Menus
Table D-1. Rosemount 3100 Series Transmitter (3102/3105)
Level 1 Level 2 Level 3 Level 4 Parameter ID and Descriptor
3102 3105
m ft. in.
m ft. in.
SETUP
(1)
DUTY P010 Bottom Reference (page 136) 11.0 36.0 432.0 11.0 36.0 432.0
Present Depth (page 121)------
SET AS EMPTY (page 120)------
P011 Tank Shape (page 143)LinearLinear
P060 Distance Offset (page 141)0.00.00.00.0 0.0 0.0
P069 Level Offset (page 142)0.00.00.00.0 0.0 0.0
P013 PV Scale Factor (page 154)1.01.01.01.0 1.0 1.0
P014 Profile Height (page 156)1.01.01.01.0 1.0 1.0
NLP CURVE P030 Profile Point 1 (page 158) 10101010 10 10
P031 Profile Point 2 (page 158) 20202020 20 20
P032 Profile Point 3 (page 158) 30303030 30 30
P033 Profile Point 4 (page 158) 40404040 40 40
P034 Profile Point 5 (page 158) 50505050 50 50
P035 Profile Point 6 (page 158) 60606060 60 60
P036 Profile Point 7 (page 158) 70707070 70 70
P037 Profile Point 8 (page 158) 80808080 80 80
P038 Profile Point 9 (page 158) 90909090 90 90
P039 Profile Point 10 (page 158) 100 100 100 100 100 100
IDENTITY P000 Message (page 131)MESSAGEMESSAGE
P001 Tag (page 132)31023105
P002 Description (page 133) 3102 XMTR 3105 XMTR
UNITS P012 PV Units (page 153)mftinmft in
OUTPUT CURRENT P015 Upper Range Value (page 159) 10.7 34.5 414.0 10.7 34.5 414.0
P016 Lower Range Value (page 160)0.00.00.00.0 0.0 0.0
P020 Damping (page 162)3.03.03.03.0 3.0 3.0
RELAYS
(2)
RELAY 1 P070 Relay 1 mode (page 163)Setpoint---
P071 Relay 1 PV On Point (page 165)0.00.00.0---
P072 Relay 1 PV Off Point (page 166)0.00.00.0---
RELAY 2 P073 Relay 2 mode (page 167)Fault---
P074 Relay 2 PV On Point (page 168)0.00.00.0---
P075 Relay 2 PV Off Point (page 169)0.00.00.0---
ENGINEERING
P021 LE Delay (page 170) 900 900 900 900 900 900
P022 LE Action (page 172) Hold Hold Hold Hold Hold Hold
P023 Upper Blanking (page 138)0.31.0120.3 1.0 12
P063 Lower Blanking (page 140)0.00.00.00.0 0.0 0.0
P024 Speed of Sound (page 174) 331.8 1088.6 13063 331.8 1088.6 13063
P025 Temperature (page 176) Auto Auto Auto Auto Auto Auto
P026 Set Threshold (page 177) Auto Auto Auto Auto Auto Auto
