Emerson Rosemount 3100 Series Reference Manual

111
Appendix D: Rosemount 3490 Series Menus
February 2015
Reference Manual 00809-0100-4840, Rev CB Rosemount 3490 Series Menus
ADVANCED P040 Tx Pwr Control (page 178)EnabledEnabled
P041 Pulse Repeat (page 179)1.01.01.01.0 1.0 1.0
P042 Echoes Needed (page 180)444444
P043 Threshold 1 Time (page 181)2.92.92.92.9 2.9 2.9
P044 Target Pulses (page 183) Auto Auto Auto Auto Auto Auto
P045 Target frequency (page 184) Auto Auto Auto Auto Auto Auto
P048 Threshold 1 Size (page 182)6.06.06.06.0 6.0 6.0
P049 Spike Rejection (page 185)000000
FALSE ECHO DATA P081 False Echo D 1 (page 186)0.00.00.00.0 0.0 0.0
P082 False Echo S 1 (page 186)0.00.00.00.0 0.0 0.0
P083 False Echo D 2 (page 186)0.00.00.00.0 0.0 0.0
P084 False Echo S 2 (page 186)0.00.00.00.0 0.0 0.0
P085 False Echo D 3 (page 186)0.00.00.00.0 0.0 0.0
P086 False Echo S 3 (page 186)0.00.00.00.0 0.0 0.0
P087 False Echo D 4 (page 186)0.00.00.00.0 0.0 0.0
P088 False Echo S 4 (page 186)0.00.00.00.0 0.0 0.0
D980 No. of false echoes stored - - - ---
FALSE ECHO ACTION P089 Clear False Echoes (page 187)------
LEARN FALSE ECHO (page 122)- - - ---
AUTO TANK MAP (page 124)------
SYSTEM SIMULATION (page 125)------
TRIM FIX CURRENT (page 128)------
TRIM 4 mA (page 129)------
TRIM 20 mA (page 129)------
RESTART DEVICE (page 126)------
LOAD DEFAULTS (page 127)------
FA
CTORY USE - - - ---
Base Units (page 118)------
FIXED P004 Final Assy No. (page 134)(Factory Set)(Factory Set)
P005 Serial Number (page 135)(Factory Set)(Factory Set)
P970 Transducer Material (page 188)PVDF PVDF
HART D949 Model Code (page 209) 52 (=3102) 53 (=3105)
D951 Poll Address (page 189)0 0
D952 Hardware Revision (page 210)(Factory Set) (Factory Set)
D953 Software Revision (page 211)(Factory Set)(Factory Set)
D960 Manufacturer (page 212)RosemountRosemount
D961 Unique ID (page 213)(Factory Set)(Factory Set)
D962 HART Revision (page 214)555555
D963 Field Device Rev. (page 215)(Factory Set)(Factory Set)
D964 Request Preambles (page 216)5 5 5 555
D965 Flags (page 217)------
Level 1 Level 2 Level 3 Level 4 Parameter ID and Descriptor
3102 3105
m ft. in.
m ft. in.
