40
Reference Manual
00809-0100-4840, Rev CB
Section 4: Starting up
February 2015
Starting up
Contents (volume) measurement
Lin Linear (factory default setting)
H.CYL.F Horizontal cylinder on its side with flat ends
SPH. Spherical vessel
H.CYL.D Horizontal cylinder on its side with dished ends
Note
This menu option is in the programming menu. See Figure C-2 on page 103 for a map of
the menu structure and how to access the menu options.
To change the contents profile
1. If entering the menu system from the PV display, press the green button repeatedly
until the “ProF” menu option is indicated (see above note).
2. Press the blue button
to enter the “ProF” menu and display the present profile
selection.
3. If the selected profile is correct, press the red button
and then the green button to
get to the next menu option. Otherwise, continue with step (4).
4. Press the blue button
to start the editing mode. The selected profile flashes to
indicate it can now be edited.
5. Press the green button
repeatedly to scroll through the list of profiles (see above).
6. Press the blue button
to confirm the new profile. (The flashing stops).
7. Press the red button
to save if the new profile is correct, or press the blue button to
not save. Afterwards, depending on the button pressed, either the “ProF” menu or the
next menu appears.
Note
If the saved profile is “Lin”, the next menu option offered is “SCALE”
(see the section “Setting the scaling factor (on the 3102/3105)” on page 44).
If another contents profile is saved, the next menu offered is “Cont @ max”
(see the section “Maximum contents (volume) entry (on the 3102/3105)” on page 47).
