Modbus Commands
9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
3454 3454 Control.Range.CurrentRange4 Word R/W current range comp4 (0=R1, 1=R2, 2=R3, 3=R4)
3455 3455 Control.Range.CurrentRange5 Word R/W current range comp5 (0=R1, 1=R2, 2=R3, 3=R4)
3456 3456
Service.Measurement.Simulation.
SimPVARawEnable1
Word R/W enable simulation for rawPVA of comp1
3457 3457
Service.Measurement.Simulation.
SimPVARawEnable2
Word R/W enable simulation for rawPVA of comp2
3458 3458
Service.Measurement.Simulation.
SimPVARawEnable3
Word R/W enable simulation for rawPVA of comp3
3459 3459
Service.Measurement.Simulation.
SimPVARawEnable4
Word R/W enable simulation for rawPVA of comp4
3460 3460
Service.Measurement.Simulation.
SimPVARawEnable5
Word R/W enable simulation for rawPVA of comp5
3471 3471 Setup.Measurement.XIntf.Enable1 Word R/W
Enable cross interference compensation for
comp1
3472 3472 Setup.Measurement.XIntf.Enable2 Word R/W
Enable cross interference compensation for
comp2
3473 3473 Setup.Measurement.XIntf.Enable3 Word R/W
Enable cross interference compensation for
comp3
3474 3474 Setup.Measurement.XIntf.Enable4 Word R/W
Enable cross interference compensation for
comp4
3475 3475 Setup.Measurement.XIntf.Enable5 Word R/W
Enable cross interference compensation for
comp5
3476 3476
Setup.Measurement.XIntf.Com-
puteFactor1
Word R/W
Compute cross interference factor comp1
(0=Src1, 1=Src2 etc.)
3477 3477
Setup.Measurement.XIntf.Com-
puteFactor2
Word R/W
Compute cross interference factor comp2
(0=Src1, 1=Src2 etc.)
3478 3478
Setup.Measurement.XIntf.Com-
puteFactor3
Word R/W
Compute cross interference factor comp3
(0=Src1, 1=Src2 etc.)
3479 3479
Setup.Measurement.XIntf.Com-
puteFactor4
Word R/W
Compute cross interference factor comp4
(0=Src1, 1=Src2 etc.)
3480 3480
Setup.Measurement.XIntf.Com-
puteFactor5
Word R/W
Compute cross interference factor comp5
(0=Src1, 1=Src2 etc.)
3501 3501 Service.Measurement.Lin.Enable1 Word R/W Enable Linearizer of comp1
3502 3502 Service.Measurement.Lin.Enable2 Word R/W Enable Linearizer of comp1
3503 3503 Service.Measurement.Lin.Enable3 Word R/W Enable Linearizer of comp1
3504 3504 Service.Measurement.Lin.Enable4 Word R/W Enable Linearizer of comp1
3505 3505 Service.Measurement.Lin.Enable5 Word R/W Enable Linearizer of comp1
3506 3506 Service.Measurement.Lin.Method1 Word R/W
Linearization method of comp1 (0=Splines,
1=Polynom)
3507 3507 Service.Measurement.Lin.Method2 Word R/W
Linearization method of comp2 (0=Splines,
1=Polynom)
3508 3508 Service.Measurement.Lin.Method3 Word R/W
Linearization method of comp3 (0=Splines,
1=Polynom)
3509 3509 Service.Measurement.Lin.Method4 Word R/W
Linearization method of comp4 (0=Splines,
1=Polynom)
3510 3510 Service.Measurement.Lin.Method5 Word R/W
Linearization method of comp5 (0=Splines,
1=Polynom)
