Data logger
Logging: Off
Sample time: 1 s
Data logger data delete!
Cached entries 14
Total entries 0
Data Selection
Export data to USB!
7.9 Logles
7.9 Handling Log Files
7.9.1 Conguring Log Files
Log les are created by the internal data
logger, event logger and calibration logger,
whereat the latter are part of optional software
upgrade packages.
Open SETUP - DATA LOGGER (this may
require to enter the access code for level 3),
to see the following menu:
Highlight the 7
th
line and open the associated
submenu to see a list of data available for
logging.
Each entry in the log le contains the following
elds
• date
• time, followed by
• the elds as selected in the menu:
For each parameter select, if it is to be included
(Yes) or not (No) in the log le:
"Concentration" includes the measured concen-
tration (ppm) and current status of all installed
channels.
"Temperature", "Flow" and "Pressure" include
the associated measured values.
Data Selection
Concentration: Yes
Temperature: No
Flow: No
Pressure: No
FieldSep: TAB
Working with log les is in the following ex-
emplarily explained on the basis of the data
logger:
The separator for the elds within an entry
is specied with the last menu line: Availa-
ble options are TAB(ulator), Comma and
SemiKol(on). Entries are separated by a car-
rige return and line feed.
Data Selection
Concentration: Yes
Temperature: No
Flow: No
Pressure: No
FieldSep: TAB
