Emerson Process Management GmbH & Co. OHG4-8
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
4.6 Analyzer Specic Instructions for Installation
4.6 Analyzer Specic Instructions for Installation
Important note for X-STREAM XEFD!
Due to the special conditions which must be observed when installing units in EX zones, the
installation of the ameproof X-STREAM XEFD version is described in a separate instruction
manual HASXEDE-IM-EX.
Even if you do not install your X-STREAM XEFD in an EX zone, please install the unit according
to the instructions in the separate manual.
Installation instructions: X-STREAM XEGK & XEGP page 4-8
X-STREAM XEXF eld housings page 4-19
Notes for wiring signal inputs and outputs page 4-31
