Emerson Process Management GmbH & Co. OHG 4-21
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
4
Installation
All dimensions in mm
[inches in brackets]
Cable glands
Connector
for potential
equalization
Gas ttings
4.6.2 Installation - X-STREAM XEXF Field Housings
Fig. 4-16: X-STREAM XDF - Dimensions for Installation
Note!
Take care to reserve space at
the right side of the instrument
for laying the cables!
