Emerson X-STREAM XE - Fig. 2-2: X-STREAM XEGK - Rear Panel and Handle Variations

Emerson Process Management GmbH & Co. OHG 2-7
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
2
Technical Data
2.2.1 Model-Specic Technical Data: X-STREAM XEGK
Fig. 2-2: X-STREAM XEGK - Rear Panel and Handle Variations
Front panel detail
6 screws (M 2.5) for rack mounting
or afxing frame & handle
Frame and handle detail
Note!
The shown rear panel options are interchangable!
Portable with handle, standard I/Os, digital I/Os, AC supply, standard gas ttings
Standard I/Os, analog inputs, DC supply, valve block
