Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 2-21
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
2
Technical Data
Fig. 2-14: X-STREAM XEFD - Power Supply Terminals / Fuse Holders
3
2
4
1
1 Power terminals with integrated
fuse holders
2 Protective earth terminal (PE)
3 Power cable entry
4 EMI power supply lter
2.2.4 Model-Specic Technical Data: X-STREAM XEFD
Fig. 2-15: X-STREAM XEFD - Signal Terminals
Note!
Depending on the actual analyzer conguration
not all shown terminal strips may be installed!
1 Ethernet & USB
2 Analog & digital I/O terminal strips
3 Max. 3 signal cables entries
1
2
3
