Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG2-20
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
Temperatures
operational, max.
*)
0 (-20) … +50 °C / 32 (-4) … 122 °F
storage -20 … +70 °C / -4 … -158 °F
Weight, max up to approx. 63 kg / 138.6 lb
IP or Type rating
IP 66, Type 4X for outdoor use,
protected against direct sun light
Measurement channels, max. 5
Gas connections
max number 8
max for purging (incl. / separate) 2 incl..
material stainless steel
sizes 6/4 mm;
1
⁄4"
Power supply unit wide range, internal
Power supply
Mains supply voltage uctuations are not to exceed
± 10 percent of the nominal voltage
nominal voltage 100–240 V
50 / 60 Hz
voltage range 85–264 V 47–63 Hz
nominal input current, max
standard, max 1.3–0.7 A
w/ temperature control, max 3–1.5 A
Power input fuses AC 230 V / T 4 A / 5x20 mm
Electrical in- and outputs
power
screw terminals with integrated fuse holders,
max. 4 mm² / 11 AWG
analog and digital I/O signals screw terminals, max. 1.5 mm² / 15 AWG
special Ethernet: RJ45 socket; USB connectors
Cable entries
to be supplied by customer, see separate insturction ma-
nual for ameproof analyzers
2.2.4 Model-Specic Technical Data: X-STREAM XEFD
*)
: Limitations apply to selected measurement principles and ranges,
Measurement specications!

Emerson X-STREAM XE Specifications

General

Brand	Emerson
Model	X-STREAM XE
Category	Measuring Instruments
Language	English
