gases. The assignments of the connectors is
given on an adhesive label situated near the
connectors.
Optional two of the ttings may be used to
purge the housing
to minimize interference
from the ambient atmosphere, or when measu-
ring corrosive and/or ammable gases. In this
1.8 X-STREAM XEFD
Fig. 1-13: X-STREAM XEFD - Front View
transport
lug
hinges
transport
lug
screws for
housing
situation special conditions apply for operation
in hazardous areas, described in the separate
manual addendum for hazardous areas.
