9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
3511 3511
Service.Measurement.Lin.Start-
Function1
Word R/W
LinFct c1: 1=On/Off 2=Calc 3=ToUSB 4=Fro-
mUSB 5=Install 6=ToFile
3512 3512
Service.Measurement.Lin.Start-
Function2
Word R/W
LinFct c2: 1=On/Off 2=Calc 3=ToUSB 4=Fro-
mUSB 5=Install 6=ToFile
3513 3513
Service.Measurement.Lin.Start-
Function3
Word R/W
LinFct c3: 1=On/Off 2=Calc 3=ToUSB 4=Fro-
mUSB 5=Install 6=ToFile
3514 3514
Service.Measurement.Lin.Start-
Function4
Word R/W
LinFct c4: 1=On/Off 2=Calc 3=ToUSB 4=Fro-
mUSB 5=Install 6=ToFile
3515 3515
Service.Measurement.Lin.Start-
Function5
Word R/W
LinFct c5: 1=On/Off 2=Calc 3=ToUSB 4=Fro-
mUSB 5=Install 6=ToFile
3516 3516
Service.Measurement.Lin.Lineariz-
erStatus1
Word RO
Lin. status comp1 (0=Normal 1=Underow
2=Overow 3=Undened)
3517 3517
Service.Measurement.Lin.Lineariz-
erStatus2
Word RO
Lin. status comp2 (0=Normal 1=Underow
2=Overow 3=Undened)
3518 3518
Service.Measurement.Lin.Lineariz-
erStatus3
Word RO
Lin. status comp3 (0=Normal 1=Underow
2=Overow 3=Undened)
3519 3519
Service.Measurement.Lin.Lineariz-
erStatus4
Word RO
Lin. status comp4 (0=Normal 1=Underow
2=Overow 3=Undened)
3520 3520
Service.Measurement.Lin.Lineariz-
erStatus5
Word RO
Lin. status comp5 (0=Normal 1=Underow
2=Overow 3=Undened)
3521 3521
Service.Measurement.Lin.Itera-
tions1
Word R/W Lin-computing iteration steps of comp1)
3522 3522
Service.Measurement.Lin.Itera-
tions2
Word R/W Lin-computing iteration steps of comp1)
3523 3523
Service.Measurement.Lin.Itera-
tions3
Word R/W Lin-computing iteration steps of comp1)
3524 3524
Service.Measurement.Lin.Itera-
tions4
Word
R/W Lin-computing iteration steps of comp1)
3525 3525
Service.Measurement.Lin.Itera-
tions5
Word R/W Lin-computing iteration steps of comp1)
3526 3526
Service.Measurement.Lin.Calc-
Sets1
Word R/W
LinFct PolySets (0=All 1=P1 2=P2 3=P3 4=P4)
comp1
3527 3527
Service.Measurement.Lin.Calc-
Sets2
Word R/W
LinFct PolySets (0=All 1=P1 2=P2 3=P3 4=P4)
comp2
3528 3528
Service.Measurement.Lin.Calc-
Sets3
Word R/W
LinFct PolySets (0=All 1=P1 2=P2 3=P3 4=P4)
comp3
3529 3529
Service.Measurement.Lin.Calc-
Sets4
Word R/W
LinFct PolySets (0=All 1=P1 2=P2 3=P3 4=P4)
comp4
3530 3530
Service.Measurement.Lin.Calc-
Sets5
Word R/W
LinFct PolySets (0=All 1=P1 2=P2 3=P3 4=P4)
comp5
4001 4001 Status.NamurStates.NamurAlarm Word RO NAMUR sum state bit-eld (b0:F b1:M b2:S b3:C)
4002 4002
Status.NamurStates.NamurAlarm-
Device
Word RO
device's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
4003 4003
Status.NamurStates.Namu-
rAlarmCh1
Word RO
comp1's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
4004 4004
Status.NamurStates.Namu-
rAlarmCh2
Word RO
comp2's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
